Stanyl® for wear & friction

For many years Stanyl is the material of choice in timing chains or chain guides in engines, bearing cages or for gear trains. The high stiffness resulting from the high degree of crystallinity provide a very good resistance to wear and good friction performance especially at high temperatures. At lower temperatures the strength of the material is especially shown at high torque levels, where normally metal gears are being applied.

Stanyl overview

Explore Stanyl® for wear & friction

Many different materials are being used in the wear and friction arena, and Stanyl is a common material in that list. For a polyamide the friction performance at high temperatures are unmatched, and for the lower temperatures, focusing on Gears the material opens up an arena that is typically dominated by metals. In the portfolio the division can be into grades specifically designed for timing chains, but also for gear trains a complete portfolio can be positioned. Glass-filled, carbon-filled or unfilled materials are available and also modified version for use of non-lubricated friction.

VIEW ALL WEAR & FRICTION GRADES

Most popular Stanyl® for wear & friction grades

Stanyl® HGR3-W (P1120D)

Add to favourites

Add this page to a list of favourites

You can find this list in your personal menu at the top of the navigation

Remove this from your favourites

Clicking this button again will remove this favourite from your profile in the top menu

"Stanyl® is our high-performance polyamide 46 used for applications in automotive, E&E, gears and outdoor power equipments."

"Stanyl® is a high performance polyamide that provides unmatched performance and value for demanding applications in which superior heat resistance, design stiffness, wear & friction and process flow qualities are required."

"Because Stanyl retains its mechanical properties at high temperatures up to 220°C, this makes it ideal for extremely high-performance applications, where it outperforms PPA, PA6T, PA9T, and often PPS and LCP."

  • Heat Stabilized
  • Wear and Friction Modified
  • "Heat stabilized"
  • "Wear and friction modified"
Envalior Plasticsfinder
Download data sheet (0KB)

Stanyl® TW341

Add to favourites

Add this page to a list of favourites

You can find this list in your personal menu at the top of the navigation

Remove this from your favourites

Clicking this button again will remove this favourite from your profile in the top menu

"Stanyl® TW341 is a V2 UL-rated, non-reinforced high heat polyamide that offers excellent wear & friction properties in combination with outstanding creep resistance, strength, stiffness and fatigue resistance especially at high temperatures in combination with cycle-time advantages and excellent flow."

"Stanyl® TW341 is a V2 UL-rated, non-reinforced high heat polyamide that offers excellent wear & friction properties in combination with outstanding creep resistance, strength, stiffness and fatigue resistance especially at high temperatures in combination with cycle-time advantages and excellent flow."

"Stanyl® TW341 is a V2 UL-rated, non-reinforced high heat polyamide that offers excellent wear & friction properties in combination with outstanding creep resistance, strength, stiffness and fatigue resistance especially at high temperatures in combination with cycle-time advantages and excellent flow."

  • Heat Stabilized
  • Lubricated
  • "Heat stabilized"
  • "Lubricated"
Envalior Plasticsfinder
Download data sheet (288KB)

Stanyl® TW200F6

Add to favourites

Add this page to a list of favourites

You can find this list in your personal menu at the top of the navigation

Remove this from your favourites

Clicking this button again will remove this favourite from your profile in the top menu

30% Glass Reinforced

"Stanyl® TW200F6 is a high heat polyamide that offers excellent creep resistance, strength, stiffness and fatigue resistance, not only at ambient temperatures but especially at high temperatures, while at the same time providing cycle-time advantages and excellent flow."

"Stanyl® TW200F6 is a high heat polyamide that offers excellent creep resistance, strength, stiffness and fatigue resistance, not only at ambient temperatures but especially at high temperatures, while at the same time providing cycle-time advantages and excellent flow."

"Stanyl® TW200F6 is a high heat polyamide that offers excellent creep resistance, strength, stiffness and fatigue resistance, not only at ambient temperatures but especially at high temperatures, while at the same time providing cycle-time advantages and excellent flow."

  • 30% Glass Reinforced
  • Heat Stabilized
  • "Heat stabilized"
Envalior Plasticsfinder
Download data sheet (290KB)



VIEW ALL WEAR & FRICTION GRADES

Featured applications

Gears

Automotive |

Envalior is a global leader in the design, engineering and testing of advanced thermoplastic materials for gears and actuation systems. Automakers and other global manufacturers trust Envalior Engineering Materials to improve the performance of complex automotive applications, appliances, consumer goods, and industrial applications. In fact, Stanyl® is used in nearly 40 million gears in 100 million automotive actuation systems each year, making it one of the most popular thermoplastic gear materials in the world.
More info

Automotive Bearing Cages

Automotive | Engine Transmission

Allows for lightweight and more economical solutions; Allows for more reliable solutions; Provides higher stiffness and chemical resistance
More info

Sustaining high performance

Stanyl is the only aliphatic polyamide that is capable of working in the field of the high-temperature polyamides, and with that it also takes the largest volume space in that area of all polymers. When focusing on the details, the core strength stems from two key properties being the high crystallization rate, which leads to small crystals, and additionally the high degree of crystallinity. These two properties create three key strengths in Stanyl, being the excellent mechanical performance at high temperatures, excellent wear and friction properties and superior flow.

Read more about Stanyl - PA46

Contact us for more information

Direct and easy access to our broad portfolio of high-performance plastics: request a quote or order a sample. You can also simply ask us a (technical) question.

Request a quote
Order a sample
Ask a question

An introduction to gears and actuators

Gears can be found everywhere: from cars to kitchen appliances and clocks. Traditionally, gears in demanding applications are made from metal, but there is an increasing demand for plastic gears. In this video, Martin Wolffs, product manager at Envalior, explains why the tooth temperature of a gear is a key property for choosing the right gear material.

Sustaining high performance

The first commercializations of Stanyl were achieved 30 years ago. Currently, it is the largest single polymer being used in the high-performance polyamide landscape. The symmetry of the chemical structure lays the foundation of its success as it provides the basis for the high degree of crystallinity and fast crystallization speed. These two features are the basis of the three key strengths of Stanyl being excellent high-temperature mechanics, excellent wear and friction performance and superior flow. These strengths are what drives the business of Stanyl. Because of these features, this materials displays exceptional retention of mechanical properties after passing through the glass transition, giving rise to its high-temperature performance.
