Stanyl® in electronics

The superior flow and high crystallinity gives Stanyl clear advantages in connector materials in both the automotive and consumer electronics domains.

Explore Stanyl® in electronics

The combination of superior flow and high temperature performance of Stanyl has been established in the past years in the automotive and consumer electronics domains. Where the high temperatures mechanics is typically reflected in the high temperature applications and in the excellent weldline performance of Stanyl, the superior flow manifests itself in domain of consumer electronics. Besides the good flow to get the parts filled in a productive manner, the high crystallization rate provides not only good cycle times in molding, but results in almost complete crystallization of PA46 in thin walled part. Besides reducing warpage of the material important in the consumer electronics, this property also brings advantages in the noise reduction in moving parts for example in e-vehicles.

Most popular Stanyl® in electronics grades

Stanyl® TE250F6

Add to favourites

Add this page to a list of favourites

You can find this list in your personal menu at the top of the navigation

Remove this from your favourites

Clicking this button again will remove this favourite from your profile in the top menu

30% Glass Reinforced

Stanyl® TE250F6 is an electro-friendly & flame-retarded high heat polyamide that offers excellent creep resistance, strength, stiffness and fatigue resistance especially at high temperatures in combination with cycle-time advantages and excellent flow.

Stanyl® TE250F6 is an electro-friendly & flame-retarded high heat polyamide that offers excellent creep resistance, strength, stiffness and fatigue resistance especially at high temperatures in combination with cycle-time advantages and excellent flow.

Stanyl® TE250F6 is an electro-friendly & flame-retarded high heat polyamide that offers excellent creep resistance, strength, stiffness and fatigue resistance especially at high temperatures in combination with cycle-time advantages and excellent flow.

  • 30% Glass Reinforced
  • Heat Stabilized
  • Flame Retardant

Stanyl® HFX61S

Add to favourites

Add this page to a list of favourites

You can find this list in your personal menu at the top of the navigation

Remove this from your favourites

Clicking this button again will remove this favourite from your profile in the top menu

35% Glass Reinforced

Stanyl® HFX61S is an electro-friendly & halogen-free flame-retarded high heat polyamide that offers an excellent combination of high CTI, flow and weld-line strength. HFX-grades are often used in connectors such as USB type C.

Stanyl® HFX61S is an electro-friendly & halogen-free flame-retarded high heat polyamide that offers an excellent combination of high CTI, flow and weld-line strength. HFX-grades are often used in connectors such as USB type C.

Stanyl® HFX61S is an electro-friendly & halogen-free flame-retarded high heat polyamide that offers an excellent combination of high CTI, flow and weld-line strength. HFX-grades are often used in connectors such as USB type C.

  • 35% Glass Reinforced
  • High Flow
  • Halogen free and free of red phosphorous
  • Good or high flow
  • Phosphorous free

Stanyl® 46HF4530

Add to favourites

Add this page to a list of favourites

You can find this list in your personal menu at the top of the navigation

Remove this from your favourites

Clicking this button again will remove this favourite from your profile in the top menu

30% Glass Reinforced

Stanyl® is our high-performance polyamide 46 used for applications in automotive, E&E, gears and outdoor power equipments.

Stanyl® is a high performance polyamide that provides unmatched performance and value for demanding applications in which superior heat resistance, design stiffness, wear & friction and process flow qualities are required.

Because Stanyl retains its mechanical properties at high temperatures up to 220°C, this makes it ideal for extremely high-performance applications, where it outperforms PPA, PA6T, PA9T, and often PPS and LCP.

  • 30% Glass Reinforced
  • Heat Stabilized
  • High Flow
  • for E&E applications
  • Good or high flow



Featured applications

E-motor electric insulation

Automotive

Application requirements High flow and mechanics Thermal conductive E-friendly HB/V0 ATF/Glycol resistant High HDT (wire welding) Material properties Thinsulation Typical UL1446 class H (0,36mm, 180°C) E-motor/E-car (thermal) load cycles

USB-C Connectors

Electronics | Desktops / PCs

Glass-reinforced ;Provides up to 50% more wear resistance compared to other high temperature polyamides ;Enables thinner wall designs ;Halogen and red phosphorous-free grades are available

Terminal Blocks

Electrical | Connectors

Most grades are available now also with halogenfree flame-retardant ingredients; Stanyl® PA46 and ForTii® PA4T to be used for SMT versions

DDR DIMM Connectors

Electronics | Connectors

Sustainable solution due to good carbon footprint; Flame retardant; Halogen-free; Red-phosphorous free

Sustaining high performance

Stanyl is the only aliphatic polyamide that is capable of working in the field of the high-temperature polyamides, and with that it also takes the largest volume space in that area of all polymers. When focusing on the details, the core strength stems from two key properties being the high crystallization rate, which leads to small crystals, and additionally the high degree of crystallinity. These two properties create three key strengths in Stanyl, being the excellent mechanical performance at high temperatures, excellent wear and friction properties and superior flow.

Contact us for more information

Direct and easy access to our broad portfolio of high-performance plastics: request a quote or order a sample. You can also simply ask us a (technical) question.

Material choice in USB-C connectors is crucial

Envalior’s Polyamide 46 (PA46), Stanyl, not only offers the highest CTI value of 600 Volt but is also the only material in the high-temperature polyamide world with a UL94-V0 specification down to 0,18mm, precisely the pitch size used in this USB-C type connector.

Stanyl also provides the lowest wear and friction so that also in challenging automotive environments, where it is specified for up to 20,000 mating cycles (plug in/plug out cycles).

From a production point of view, it provides the highest flow which offering molders and connector manufacturers a lot of added value because it increases productivity / reduces manufacturing costs.

Sustaining high performance

The first commercializations of Stanyl were achieved 30 years ago. Currently, it is the largest single polymer being used in the high-performance polyamide landscape. The symmetry of the chemical structure lays the foundation of its success as it provides the basis for the high degree of crystallinity and fast crystallization speed. These two features are the basis of the three key strengths of Stanyl being excellent high-temperature mechanics, excellent wear and friction performance and superior flow. These strengths are what drives the business of Stanyl. Because of these features, this materials displays exceptional retention of mechanical properties after passing through the glass transition, giving rise to its high-temperature performance.
